Your present location:Home >> 3-Color EPD >> 2.7 inch color e-paper display yellow e-ink screen module GDEW027H64
  • Product Name: 2.7 inch color e-paper display yellow e-ink screen module GDEW027H64
  • Code: 02705
  • Quantity in stock: --
  • Retail price: --
  • Unit of measurement: --
  • Net weight: --
  • Views : 89

This is a color 2.7 inch e-paper display with 264x176 resolution, 24 pins FPC connection, optional FPC connector, communicating via SPI interface, with embedded controller(COG package) and on-chip stored waveform,  supports black, white and yellow.

In view of so many advantages: ultra low power consumption, near 180 degree view angle, readable under sunlight, GDEW027H64 is a very good choice for applications like shelf label, smart tags, smart home application, industrial instrument, IED and other related products.
Note: All of 3-color epaper doesn't support partial refesh.





· Three colors, black, white and yellow

· Higher resolution, 264x176

· The I2C signal master interface to read built-in temperature sensor.

· Come with helpful development resources and manual (STM32 platform )

· Development platform available STM32 / Arduino / Raspberry Pi / ESP8266









Part Number

GDEW027H64

Type

Dot Matrix

Resolution

264x176(DPI:117)

Outline Size(mm)

70.42x45.8x0.98

Active Size(mm)

57.288x38.192

Pixel Pitch(mm)

0.217x0.217

Operating Temp.

0℃~40℃

Storage Temp.

-25℃~60℃

Connector

24 Pin FPC, Pitch:0.5mm

Interface

SPI

Color

Black,White,Yellow

Time of refresh(s) 16(Typ), 43(Max)









Part Number

Color

Feature

Full refresh time

T/P(optional)
GDEW027W3 Black, White Partial refresh, 4 Grayscale 3s
GDEW027C44 Black,White,Red Three colors 16s
GDEW027H64 Black,White,Yellow Three colors 16s
GDEW027W3-T Black,White Partial refresh, Touch screen, 4 Grayscale 3s
GDEW027C44-T Black,White,Red Three colors, Touch screen 16s







File Type

Description (Downloadable)

Version

Language

Update Date

Size

GDEW027H64 Specification

3.2

English

2019-10-22

1.32MB

IC Driver 1.0 English 2017-08-11 441.15KB
Connector Spec. 1.0 English 2017-08-11 1.77MB







STM32 Development Board



File Type

Description (Downloadable)

                 Version

               Language

       Update Date

       Size

DESPI Specification

                   1.0

               English

       2018-07-12

      673.62KB

DESPI-C02-SCH

                   1.0                English        2018-07-12         701.28KB
DESPI-M02-SCH                    1.0                English        2018-07-12         1.2MB
GDEW027H64 STM32 Code               1.0            English      2019-10-22      2.32MB



Arduino Development Board

File Type

Description (Downloadable)

                 Version

               Language

       Update Date

       Size

 DEArduino Specification

                   1.0

               English

       2018-11-28

      673.62KB

DESPI-C02-SCH

                   1.0                English        2018-11-28         701.28KB
DEArduino UNO for EPD_SCH               1.0             English       2018-11-28       462.58KB
GDEW027H64 Arduino Code               1.0             English      2019-10-22        14.59KB



Rasberry Pi Development Board



File Type

Description (Downloadable)

                 Version

               Language

       Update Date

       Size

DESPI Specification

                   3.0

               English

       2019-09-12

      673.62KB

DESPI-C03-SCH

                   1.0                English        2019-09-27         701.28KB
DESPI-M02-SCH                    1.0                English        2018-07-12         1.2MB

ESP8266



File Type

Description (Downloadable)

                 Version

               Language

       Update Date

       Size

 ESP8266(C02) Specification

                   1.0

               English

       2020-04-02

      939.11KB

 ESP8266(C03)Specification                  1.0              English       2020-04-02       1.04MB
 Esp8266(C102_30P) Specification                  1.0               English       2020-04-02        932.32KB

 ESP8266 for EPD-SCH

                   1.0                English        2020-01-07         72.68KB
 DESPI-C02-SCH                    1.0                English        2018-07-12         72.68KB









File Type

Description (Click to see more)

Language

Update Date
The Principle and Advantage of E-Paper English 2012-10-25
Matrix E-ink Display -- FAQ English 2017-08-16
Matrix E-ink Display -- FAQ Pt. 2 English 2018-11-13
Product list-1 English 2018-09-29
Product list-2 English 2018-09-29
Product list-3 English 2018-09-29
RoHS English 2018-12-27

Warranty

English

2016-10-25

Precautions for E-paper Display

English 2019-03-11
