GDEP097TC2 is a reflective electrophoretic E Ink technology display module based on active matrix TFT substrate. It has 9.7” active area with 1200 x 825 pixels, the display is capable of displaying images at 2-16 gray levels (1-4 bits) depending on the display controller and the associated waveform file it used.
· Partial refresh
· Parallel interface
· 16 Grayscale
· 1200x825 resolution
· Come with helpful development resources and manual (STM32 platform )
|
Model
|
GDEP097TC2
|
|
Size
|
9.7 inch
|
|
Active Area |
202.8 (H)×139.425 (V) |
|
Display Resolution
|
1200x825
|
|
Pixel Pitch
|
0.169 (H)x0.169 (V)
|
|
Outline Dimension
|
218.8(W)×156.425(H)×1.15(D)
|
|
Weight
|
80 ± 8
|
|
Number of Grey
|
16 Grey Level (monochrome)
|
|
Operating Temp. |
0 to +50 |
|
Storage Temp. |
-25 to +70 |
|
Power consumption of the refresh(mW) |
3980 |
|
Standby power consumption Pc(mW) |
0.6 |
|
Time of refresh(s) |
1 |
|
Time of partial refresh(s) |
1 |
|
